16 Inch Mega Beam Clamp 3 ton
16 Inch Mega Beam Clamp 3 ton

16" Mega-Beam Clamp, Black Anodized

16 Inch Mega Beam Clamp 3 ton

Each Beam Clamp can close to as small as 2".

16 Inch Mega Beam Clamp 3 ton

Beam Clamp with Optional Mega-Couplers attached.

16 Inch Mega Beam Clamp 3 ton

Optional Beam Clamp Jaws can be added to any size Beam Clamp to fit up to 2" Beam Flanges.

16 Inch Mega Beam Clamp 3 ton

Optional Beam Clamp Jaws attached.

The Mega-Beam Clamp is a low profile sliding jaw design that allows you to secure your load as close to the I-Beam as possible. The 16" model has a 3 ton rating. The two aircraft aluminum jaws are adjusted on the 3/4"-6" tip Acme threaded shaft. The spring loaded handle locks after adjustment. Aluminum construction is half the weight of steel units and has a wider gripping range.

Fastens from 2 inch to 16 inch wide I-Beam flanges up to 1" thick. Center hole is 1-1/2"


Optional Mega-Couplers can be attached to any size Beam Clamp (see photo on right). Couplers are attached to fit standard 12" truss. If you are attaching to any other size truss (such as Global Truss) it is important to note when ordering. Coupler is part # MLM1/2CS for Mill Finish Beam Clamps and # MLB1/2CS for Black Beam Clamps.


Optional Beam Clamp Jaws can be added to any size Beam Clamp to fit up to 2" thick Beam Flanges (see photo on right). Part # MBC2INCHJAWS


Download Spec Sheet (PDF)
Safe Vertical Working Load

6000 lbs / 2720 kg

Dimensions

22.5" L x 7.5T x 2.75"WCenter Hole – 1 1/2"

Weight

15.20

Case Quantities

each

Order Codes

MBC3T-16B 16 Inch Mega Beam Clamp 3 ton, Black Anodized
MBC3T-16M 16 Inch Mega Beam Clamp 3 ton, Silver
